| PARAMETER | SPECIFICATION | DETAILS |
|---|---|---|
| Model | MMA-400M (415V) | ARC Series |
| Input Power Supply | AC 415V ±15% | 3 Phase |
| Input Frequency | 50 / 60 Hz | — |
| Input Current | 24 A | At Rated Load |
| No Load Voltage | 65 V | — |
| Output Current Range | 20 – 400 A | Adjustable |
| Rated Output Current (Real Current) | 340 A | Continuous Duty |
| Rated Output Voltage | 36 V | At 340A |
| Duty Cycle | 100% | Heavy Duty |
| Efficiency | 85% | — |
| Power Factor | Cos φ 0.93 | — |
| Insulation Class | F | — |
| Protection Class | IP21S | — |
| Cooling | Forced Air Cooling | — |
| Dimensions (L x W x H) | 580 x 260 x 430 mm | Approx. |
| Net Weight | 23 Kg | Approx. |
